Page #30 background imageLoading...
Page #30 background image
E6 28 DTR.APC.APR.ALW.03(ENG)
5. TECHNICAL DATA
5.1. APC..., APR... Common parameters
5.1.1. APC..., APR... Electrical parameters
Versions
of the transmitter
Minimum supply
voltage at transmitter
terminals
Umin [V] DC
Maximum supply
voltage at transmitter
terminals
Umax [V] DC
Notes
normal
10
55V DC
intrinsically Safe (Exi)
10,5
30V DC
see Appendix Exi.03, Exi.04
explosion proof (Exd)
13,5*
45V DC
see
Appendix Exd.01, Exd.02
explosion proof NN(Exd)
13,5
55V DC
MID (Exi)
13,5*
28V DC
see Appendix MID
MID (Exd)
13,5*
45V DC
see Appendix MID
*) Backlight setting of indicates increases the minimum supply voltage for all versions by 3V;
Output signal 4÷20mA + HART rev.5.1
Communication with the transmitter to check its configuration parameters is carried out via HART transmission
protocol and signal of 4÷20mA. For this purpose: KAP-03, KAP-03Ex communicator, HART/RS232 converter or
HART/USB Converter (APLISENS) or another converter, PC computer and Raport 2 programme can be used.
Resistance of power supply cables or resistors for communication, and output resistance of the power supply
can lead to voltage drops on the way from the power supply to transmitter terminals. Therefore, the maximum
resistance permitted to be included in a series circuit with the power supply should be calculated (Rmax load
resistance). The total resistance in the Ro current loop must be lower than this value to ensure the minimum
voltage on the terminals of the converter throughout the current loop operating range (up to 22.5 mA with regard
to HART alarms and communication).
The resistance necessary for communication (HART) min 240Ω
The maximum values of Rmax permissible load resistance for the supply voltage of the power supply (Usup[V]
DC) should be calculated based on the following formula:
Rmax[]
=
When the Ro total load resistance in the current loop is given, the minimum supply voltage (Usup [V] DC)
required for the use of the power supply can be calculated likewise.
Usup[V] = Umin[V] + 0,0225 [A] x Ro[]
where:
Rmax maximum permissible load resistance for a specific voltage of the power supply.
Ro total resistance in the current loop
Usup supply voltage
The maximum length of the connection cable 1500m
Output updating time 16…480ms (programmable)
150ms version Exd
Additional electronic damping 0...60s
5.1.2. APC..., APR... Construction materials
Diaphragm seal for APC... Stainless steel 1.4404/1.4435(316L)(PED version) or Hastelloy C276
Diaphragm seal for APR... Stainless steel 1.4404/1.4435(316L)(PED version) or Hastelloy C276
Sensing module Stainless steel 1.4404 (316L)
Liquid filling the interior the sensing module Silicone oil, chemically inactive liquid for measurement of
oxygen uses.
Connectors for APC... Stainless steel 1.4404 (316L) or
Hastelloy C276 only for P, GP, CM30x2
C-type vented covers and connectors for APR... Stainless steel 1.4404 (316L)
Usup[V] Umin[V]
0,0225[A]
