5.3. APR-2000ALW, APR-2200ALW
Measurement ranges and metrological parameters
5.3.1. APR-2000ALW. Measurement ranges
N

Nominal measuring range
(FSO)
Minimum set range
Rangeability
Overpressure limit
Static pressure
limit
1
0…70bar (0…7MPa)
7bar (700kPa)
10:1
C-type: 250, 320, 420bar
(PS=275bar for PED version)
(P-type: 40bar)
2
0...16bar (0...1.6MPa)
1.6bar (160kPa)
10:1
3
0...2.5bar (0...250kPa)
0.2bar (20kPa)
12.5:1
4
0...1bar* (0...100kPa)
50mbar (5kPa)
20:1
5
0...0.25bar* (0...25kPa)
10mbar (1kPa)
25:1
6
-0.5…0.5bar* (-50…50kPa)
0.1bar (10kPa)
10:1
7
-100...100mbar* (-10...10kPa)
10mbar (1kPa)
20:1
8
-5...70mbar* (-0.5...7kPa)
4mbar (0.4kPa)
18:1
9
-25...25mbar* (-2.5...2.5kPa)
2mbar (0.2kPa)
25:1
C-type: 200bar; P-type: 40bar
10
-7...7mbar** (-0.7...0.7kPa)
1mbar (0.1kPa)
14:1
20bar)
*) available also in HS version………**) available only in HS version
5.3.2. APR-2200ALW. Measurement ranges
Nominal range
(FSO)
Minimum set
range
Vertical spacing
of diaphragm
seals.
Maximum configurable range dependent
on the actual vertical spacing of
diaphragm seals (m)
Static
pressure
limit
-160...160 mbar
0.1 mH2O
 1.7m
[1.6+( vertical spacing of sealsx0.94)]mH2O
40bar
-0.5...0.5 bar
0.5 mH2O
 6m
[5+(vertical spacing of sealsx1.04)]mH2O
40bar
-1.6...2 bar
1.5 mH2O
 15m
[20+(vertical spacing of sealsx1.04)]mH2O
40bar
-1.6...16 bar
1bar
 15m
16bar
40bar
The maximum vertical diaphragm seal spacing shown in the table applies to level measurement,
ensuring that it is possible to set the zero point of the transmitter when the tank is empty.
For measurements of density or phase boundaries (in the sugar and chemical industries and
in refineries) the vertical spacing of the diaphragm seals can be larger.
5.3.3. APR-2000ALW, APR-2200ALW. Permitted environmental conditions
Operating temperature range -25º ÷ 85ºC (for PED version in accordance with p.5.3.5)
Special version -40º ÷ 85ºC
Operating temperature range for intrinsic-safe versions in accordance with Appendix Exi.ATEX
or Appendix Exi.IECEx.
Operating temperature range for flame-proof versions in accordance with Appendix Exd.ATEX
or Appendix Exd.IECEx.
Medium temperature range -25º ÷ 120ºC – for direct measurement,
for PED version in accordance with p. 5.3.6
over 120ºC measurement with a transmission
tube or diaphragm seal using
Thermal compensation range -25º ÷ 80ºC
Relative humidity max 98% with condensation
For transmitters with diaphragm seals permissible temperature and corrosive properties of the medium depend
on the type of separators, see see Catalogue Cards.
