Aplisens APR-2000ALW User Manual

E6 59 DTR.APC.APR.ALW.03(ENG)
15


M30x2
+0,1
1,25
2
diaphragm seal


M20x1.5

25
M20x1,5

5

M30x2

16
2

30°
1,25
M20x1.5
2
min.15
M20x1,5
19
1,25

3

min.15
+0,1
15
diaphragm seal
2
2
M30x2
The ring in Fig. 8c has to be welded in place with the word TOP upwards.
Fig. 6. M-type connector with M20x1.5 thread.
Fig. 7. P-type connector with M20x1.5 thread.
Fig. 8. CM30x2-type connector with flush diaphragm with M30x2 thread.
i
TOP
Fig.6a. M-type connector
with M20x1.5 thread
Fig.6b. Socket for M-type connector
Fig.7a. P-type connector
with M20x1.5 thread
Fig.7b. Socket for P-type connector
Fig.8a. CM30x2-type connector
with flush diaphragm
with M30x2 thread,
Fig.8b. Socket for
CM30x2-type
connector.
Fig.8c. Socket for
CM30x2-type connector
Sealing: teflon
Order code Socket CM30x2
