94
40
0x0000008000000000
Eq1
L1
Reactive Energy
41
0x0000010000000000
Eq2
L2
42
0x0000020000000000
Eq3
L3
43
0x0000040000000000
Eq123
L123
44
0x0000080000000000
Es1
L1
Active Energy
45
0x0000100000000000
Es2
L2
46
0x0000200000000000
Es3
L3
47
0x0000400000000000
Es123
L123
48
0x0000800000000000
Upp12
L1-L2
Voltage between phases
49
0x0001000000000000
Upp23
L2-L3
50
0x0002000000000000
Upp31
L3-L1
51
0x0004000000000000
phUpp1223
L12-L23
Phase Shift of phase voltage
52
0x0008000000000000
phUpp2331
L23-L31
53
0x0010000000000000
phUpp3112
L31-L12
54
0x0020000000000000
psU
-
Phase Sequence of voltage
55
0x0040000000000000
psI
-
Phase Sequence of current
56
0x0080000000000000
rU1
L1
Voltage Range
57
0x0100000000000000
rU2
L2
58
0x0200000000000000
rU3
L3
59
0x0400000000000000
rI1
L1
Current Range
60
0x0800000000000000
rI2
L2
61
0x1000000000000000
rI3
L3
62
0x2000000000000000
Reserved / not used
63
0x4000000000000000
Reserved / not used
64
0x8000000000000000
Reserved / not used
MEAS:VAL:CONF?
Request to get the configuration word of MEAS:VAL? command. Answer values are two comma
separated numbers within range: decimal (0 - 4294967295). To understand the meaning of these
numbers, converse them to hexadecimal and see previous command’s table.
MEAS:VAL:UI?
Request for aggregated result of voltages and currents.
MEAS:VAL:UIP?
Request for aggregated result of voltages, currents and phases.
MEAS:VAL:PUI?
Request for aggregated result of active powers, voltages and currents.
MEAS:VAL:PUIP?
Request for aggregated result of active powers, voltages, currents and phases.
MEAS:VAL:PQS?
Request for aggregated result of active, reactive and apparent powers.
MEAS:TIM?
Request for “time base” value
MEAS:TIM {<time>}
Setting the “time base” value. Valid range is 1s – 100s.
