APsystems YC500A - YC500 I Installation Procedures; Step 1: Position AC Bus Cable; Step 2: Install AC Branch Circuit Junction Box; Step 3: Attach Microinverters to Racking or PV Module Frame

YC500A Installation/User Manual
13
Installation Procedures
1 2
3
4 5 6 7
8
9 10 11 12 13 14 15 1716 18 19 20 2221
APsystems Microinverter&Energy Communication Unit
Warranty Card
The APsystems Installation Map is a diagram of the physical location of each microinverter in your PV installation.
Each APsystems microinverter has a removable serial number label located on the mounting plate. Pee l the label
and affix it to the respective location on the APsystems installation map.
Installation Map Template
To register your APsystems microinverter, please mail this warranty registration card to: emasupport@altenergy-power com.
B A
B A
B A
Figure 14
NOTE: 1. The layout of the inverters' serial numbers on the warranty
card is only suitable for general arrangement.
2. Step 1~5 can be done in any order..
3. Warranty card is located in Appendix last page of this manual.
4. You can use Scanning Gun or mobile phone to scan the
serial numbers on the map when set ECU (see ECU manual).
5. Using apsystems' mobile app ArrayApp can make the
installation and registion much more simple.
