APsystems YC500A - Replace a Microinverter

YC500A Installation/User Manual
21
Wiring Diagram
Sample Wiring Diagram - Three Phase
Figure 16
AC ISOLATOR
AC BRANCH END CABLE
BROWN - LIVE BLACK - NEUTRAL YELLOW/GREEN - GROUND
METER
BRANCH END CAP
INSTALLED O N THE
OPEN A C CONNECTOR
UP TO 10 YC500 PER
BRANCH CIRCUIT
25 AMP CIRCUIT
BREAKER PER
BRANCH CIRCUIT
TO METER
OR AC
DISTRIBUTION
PANEL
NEUTRALGROUND
DISTRIBUTION PANEL
THREE PHASE
SOLAR
PANEL
ETHERNET CONNECTION TO BROADBAND ROUTER
APsystems
YC500
ENERGY COMMUNICATION UNIT
230 VAC POWER CABLE
ECU
