YC500A Installation/User Manual
19
APsystems YC500A Microinverter Datasheet
Model
YC500A-SAA
Input Data (DC)
MPPT Voltage Range
22V-45V
Operation Voltage Range
16V-52V
Maximum Input Voltage
55V
Startup Voltage
22V
Maximum Input Current
10.5A x 2
Output Data (AC)
Maximum Output Power
530W
Nominal Output Voltage
230V
Maximum Continuous Output Current
2.30A
Default Output Voltage Range
200V-270V
*
Extended Output Voltage Range
149V-278V
Nominal Output Frequency
50Hz
Default Output Frequency Range
47.5Hz-50.5Hz
*
Extended Output Frequency Range
45.1Hz -54.9Hz
Power Factor
>0.99
Total Harmonic Distortion
<3%
Maximum Units per Branch
9 for 20 Breaker
**
/ 11 for 25A Breaker
**
Efficiency
Max. Inverter Efficiency
95.5%
Night Power Consumption
120mW
Mechanical Data
Operating Ambient Temperature Range
-40
o
F to +149
o
F (-40 °C to +65 °C )
Storage Temperature Range
-40
o
F to +185
o
F (-40 °C to +85 °C )
Dimensions (W x H x D)
221mm x 167mm x 29mm (8.7” x 6.6” x 1.1”)
Weight
5.5lbs/2.5kg
Enclosure Rating
IP67
Cooling
Natural Convection - No Fans
Features & Compliance
Communication
Power Line Communication
Monitoring
Via EMA Software
Safety Class Compliance
EN 62109-1; EN 62109-2;AS3100
Grid Connection Compliance
AS 4777.2/AS 4777.3
© All Rights Reserved
Specifications subject to change without notice - please ensure you are
using the most recent update found at www.APsystems.com
*
Programmable through ECU to meet customer need.
**
Depending on the local regulations.
2017/9/12 Rev1.1
