APsystems Microinverter System Installation
A PV system using APsystems Microinverters is simple to install. Each
Microinverter easily mounts on the PV racking, directly beneath the PV
module(s). Low voltage DC wires connect from the PV module directly
to the Microinverter, eliminating the risk of high DC voltage.
Installation MUST comply with local regulations and technical rules.
Special Statement! An AC GFCI device should not be used to protect the
dedicated circuit to the APsystems microinverter even though it is an outside
circuit. None of the small GFCI devices (5mA-30 mA) are designed for back
feeding and will be damaged if back feed. In a similar manner, AC AFCIs
have not been evaluated for back feeding and may be damaged if back feed
with the output of a PV inverter.
WARNING: Perform all electrical installations in accordance with
localelectrical codes.
WARNING: Be aware that only qualified professionals should install
and/or replace APsystems Microinverters.
WARNING:
Before installing or using an APsystems Microinverter,
please read all instructions and warnings in the technical documents
and on the APsystems Microinverter system itself as well as on the
PV array.
WARNING: Be aware that installation of this equipment includes
the risk of electric shock.
WARNING: Do not touch any live parts in the system, including the
PV array, when the system has been connected to the electrical grid.
NOTE: Strongly recommend to install Surge protection Devices in
the dedicated meter box.
Additional Installation components from APsystems
