40
11.4 General Specifications
MODEL 8KW48Vdc
Safety Certification CE
Operating Temperature Range -10°C to 50°C
Storage temperature -15°C~ 60°C
Humidity 5% to 95% Relative Humidity (Non-condensing)
Dimension
(L*W*H), mm
554*420*153
Net Weight, kg 18.4
12. Installation Dimension Drawing
(unit:mm)
NOTE: The following picture is only a schematic diagram of the equipment .If the actual chassis does not
conform to the schematic due to a structural upgrade, it is subject to prior notice.
