AQUAERO 5 / AQUAERO 6
● Plug for PWM connector, 2 contacts (53036)
4.5.
4.5.4.5.
4.5. Connector “IR LED”
Connector “IR LED”Connector “IR LED”
Connector “IR LED”
Not operational, reserved for future use.
4.6.
4.6.4.6.
4.6. Connector “aquabus high”
Connector “aquabus high”Connector “aquabus high”
Connector “aquabus high”
Connector for communication with other devices from Aqua Computer.
Compatible products:
● Real Time Clock module (53127)
● Aqua Computer D5 NEXT (41118)
● aquastream ULTIMATE (41108)
● aquastream XT ( 41059/41060/41061)
● QUADRO (53256)
● Calitemp digital temperature sensor (53257)
● aquabus X4 (53258)
● Flow sensor “high flow USB” (53129)
● Flow sensor mps flow 100/200/400 (53130/53131/53132)
● poweradjust 3 USB (53166/53167)
● poweradjust 2 USB (discontinued, firmware version 1003 or higher required)
● farbwerk (53170/53207)
● aqualis XT series
● aquainlet XT series
● pump adapter for aqualis with integrated fill level sensor
● mps pressure ∆40/100/500/1000 (53133/53134/53135/53160)
● VISION series
● aquabus / speed signal cable 3 pin (article no. 93111/53161)
● aquabus Y adapter 3 pin (article no. 53063)
● aquabus cable 4 pin (article no. 53122/53162)
● aquabus Y adapter 4 pin (article no. 53124)
● aquabus cable 4 pins for VISION, QUADRO, D5 NEXT (article no. 53214)
Please note:
Please note:Please note:
Please note: The aquabus connector is also compatible with 3 pin aquabus de-
vices. The additional “pin 4” supplies power to compatible 4 pin aquabus devices.
For example, a poweradjust 3 unit (3 pin) and a mps flow 200 unit (4 pin) can si-
multaneously be connected using a 4 pin Y adapter cable (art. 53124).
Pin assignment: Pin 1: GND
Pin 2: SDA
Pin 3: SCL
Pin 4: +5 V
4.7.
4.7.4.7.
4.7. Connector “RPM/Tacho”
Connector “RPM/Tacho”Connector “RPM/Tacho”
Connector “RPM/Tacho”
Depending on configuration, the aquaero 5/6 can generate a speed signal which
is available for processing through this connector. This speed signal can for exam-
© 2014-2019 Aqua Computer GmbH & Co. KG - 9 -
