26
UK
Place the back nuts onto the tap tails and secure the assembly to
the underside of the bath.
Using suitable connections, connect the tap tails to the hot and cold supplies.
Turn on the supplies to the bath/shower mixer and turn the flow control knob on to flush the system
through. Turn o the bath/shower mixer and attach the hose, ensuring the hose washer is in place.
If required, refer to the commissioning instructions on page 32 to adjust the maximum
temperature override button position.
Follow the Midas 110/220 adjustable height head installation on page 16 to complete the
installation.
3
4
5
6
