ARAG IBX100 - Wiring Harness Connection

8
INSTALLATION
5.3 
IBX100 SPRAYER

IBX100 HYDRAULIC
(FOR SELETRON SYSTEM, ONLY)
NO. CONNECTION POINTS
1
Hydraulic unit
2
ECU IBX100 Sprayer
NO. CONNECTION POINTS
1

2
Control unit (section valves)
SYSTEM WITH
SECTION VALVES
3
Hydraulic unit
2
Seletron - Line 2
SYSTEM WITH
SELETRON
3
Seletron - Line 1
4
Standard ISOBUS connector
(ISOBUS PLUG)

