ARAG IBX100 - Pin-out of IBX100

72
TECHNICAL DATA
18.1 
VALVE sprayer technology

A
SENSOR CABLE
PIN IBX100 signal
 
 Pressure sensor (M)
 Level sensor (L)
 -
 -
 -
 -
 GND sensor power supply
 Proportional valve
 Spraying activation / deactivation
 -
 -
 -
 -
 -
 
 Proportional valve
 Speed sensor (S)
 Flowmeter (F)
 Filling flowmeter (T)
 RPM sensor (X)
 Flashing light (Z)
 Boom lighting (Z)
 G GND valve power supply
B
H2O VALVES
(7/14 sections)
PIN IBX100 signal
 GND power supply
 
 
 
 
 
 
 
 GND power supply
 
 -
 -
 
 
 Fence
 
 GND Fence power supply
 
 
 
 
 
 Fence Activation
 
C
HYD VALVES
PIN IBX100 signal
 AC valve
 AA valve
 BC valve
 BA valve
 CC valve
 CA valve
 DD valve
 -
 Hyd valve GND power supply
 
 
 
 
 
 
 -
 -
 
 
 
 
 
 
 Hyd valve GND power supply
D
ISOBUS CABLE
Tractor / Self-propelled
PIN IBX100 signal
 PWR
 -
 -
 -
 -
 -
 PWR
 PWR
 PWR GND
 -
 CAN L
 CAN H
 -
 -
 ECU-POWER
 PWR
 PWR GND
 PWR GND
 -
 -
 TBC-POWER
 TBC GND
 ECU-POWER GND
 PWR GND
