3.1) Align the seal along the sides of the tub. Ensure the
seal inner edge is aligned to touch the tags on the
rear corner brackets on the inner edge.
Apply the seal with firm pressure to the tub.
3.2) Around the front corners of the tub, apply the
primer stick (665044) to the front rubber bridges.
(Break the vial at the dots by squeezing and wet out
the felt tip to apply the primer). Allow the primer to
dry.
3.3) Apply the seal along to the front bracket at an even
offset to the inside of the tub. Ensure the seal inner
edge is aligned to touch the tags on the front corner
brackets on the inner edge.
Apply the seal with firm pressure to the tub.
