6.29) Refit the bolts, tie down hooks and spacers
(6250027) from the canopy’s hardware kit to the
front tub corner canopy mounting brackets, the
rear tie down mounts and tighten to 22Nm.
REAR Lower Tie Down Point
6.30) Refit the bolts, tie down hooks and spacers to the
rear lower tie down mounts and tighten to 22Nm.
6.31) Refit the bolts and spacers (6250026 & 6250027)
from the canopy’s hardware kit to the rear tub
corner canopy mounting brackets and tighten to
22Nm.
Return to step 2.2 and complete fitting using
the spacers as described when fitting the tub
mounting brackets.
