Care must be taken that firstly the heater socket on the inner body must be removed in order
to disassemble the connection on the upper part.
After removing the socket connection, the group called heater pipe group which is connected
with two screws is disassembled through unscrewing. As shown in the figure, the group is
demounted wholly by being held and pulled from the silicon part.
Important: Do not let the water pipes bend on any point while re-assembling the group.
Besides, after assembly, the blue tape on the water intake as shown in the figure must be
removed. Otherwise, water intake of the system will be blocked.
