Arcom RC-210 User Manual

29
Macro Function Number List
FN Description FN Description
001 Port 1 Carrier Access 061 Port 2 Courtesy Tone 3
002 Port 1 CTCSS Access 062 Port 2 Courtesy Tone 4
003 Port 2 Carrier Access 063 Port 2 Courtesy Tone 5
004 Port 2 CTCSS Access 064 Port 2 Courtesy Tone 6
005 Port 3 Carrier Access 065 Port 2 Courtesy Tone 7
006 Port 3 CTCSS Access 066 Port 2 Courtesy Tone 8
007 Port 1 DTMF Covertone OFF 067 Port 2 Courtesy Tone 9
008 Port 2 DTMF Covertone OFF 068 Port 2 Courtesy Tone 10
009 Port 3 DTMF Covertone OFF 069 Port 3 Courtesy Tone 1
010 Port 1 DTMF Covertone ON 070 Port 3 Courtesy Tone 2
011 Port 2 DTMF Covertone ON 071 Port 3 Courtesy Tone 3
012 Port 3 DTMF Covertone ON 072 Port 3 Courtesy Tone 4
013 Port 1 Enable 073 Port 3 Courtesy Tone 5
014 Port 1 Disable 074 Port 3 Courtesy Tone 6
015 Port 2 Enable 075 Port 3 Courtesy Tone 7
016 Port 2 Disable 076 Port 3 Courtesy Tone 8
017 Port 3 Enable 077 Port 3 Courtesy Tone 9
018 Port 3 Disable 078 Port 3 Courtesy Tone 10
019 Monitor Port 1 from Port 2 079 Port 1 DTMF Muting ON
020 Monitor Port 1 from Port 3 080 Port 2 DTMF Muting ON
021 Disconnect Port 1 from Port 2 081 Port 3 DTMF Muting ON
022 Disconnect Port 1 from Port 3 082 Port 1 DTMF Muting OFF
023 Port 1 Monitor Mute 083 Port 2 DTMF Muting OFF
024 Port 1 Monitor Mix 084 Port 3 DTMF Muting OFF
025 Monitor Port 2 from Port 1 085 Control Receiver Override ON
026 Monitor Port 2 from Port 3 086 Control Receiver Override OFF
027 Disconnect Port 2 from Port 1 087 Read ADC Channel 1
028 Disconnect Port 2 from Port 3 088 Read ADC Channel 2
029 Port 2 Monitor Mute 089 Read ADC Channel 3
030 Port 2 Monitor Mix 090 Read ADC Channel 4
031 Monitor Port 3 from Port 1 091 Read ADC Channel 5
032 Monitor Port 3 from Port 2 092 Read ADC Channel 6
033 Disconnect Port 3 from Port 1 093 Read ADC Channel 7
034 Disconnect Port 3 from Port 2 094 Read ADC Channel 8
035 Port 3 Monitor Mute 095 UF1 ON
036 Port 3 Monitor Mix 096 UF1 OFF
037 Port 1 Full Duplex 097 UF1 Pulse
038 Port 1 Half Duplex 098 UF2 ON
039 Port 2 Full Duplex 099 UF2 OFF
040 Port 2 Half Duplex 100 UF2 Pulse
041 Port 3 Full Duplex 101 UF3 ON
042 Port 3 Half Duplex 102 UF3 OFF
043 Port 1 Speech Override ON 103 UF3 Pulse
044 Port 2 Speech Override ON 104 UF4 ON
045 Port 3 Speech Override ON 105 UF4 OFF
046 Port 1 Speech Override OFF 106 UF4 Pulse
047 Port 2 Speech Override OFF 107 UF5 ON
048 Port 3 Speech Override OFF 108 UF5 OFF
049 Port 1 Courtesy Tone 1 109 UF5 Pulse
050 Port 1 Courtesy Tone 2 110 UF6 ON
051 Port 1 Courtesy Tone 3 111 UF6 OFF
052 Port 1 Courtesy Tone 4 112 UF6 Pulse
053 Port 1 Courtesy Tone 5 113 UF7 ON
054 Port 1 Courtesy Tone 6 114 UF7 OFF
055 Port 1 Courtesy Tone 7 115 UF7 Pulse
056 Port 1 Courtesy Tone 8 116 Say Time
057 Port 1 Courtesy Tone 9 117 Say Date
058 Port 1 Courtesy Tone 10 118 Link Port 1 to Port 2
059 Port 2 Courtesy Tone 1
060 Port 2 Courtesy Tone 2
