Programming Commands Quick Reference
Code What It Programs What It Means
*1000 Program Transmitter Hang Timer Programs the xmtr Hang Timer for the currently unlocked Port
*1001 Program Time Out Time Programs the Timeout Timer for the currently unlocked Port
*1002 Program Initial ID Period Programs the Initial ID Timer for the currently unlocked Port
*1003 Program Pending ID Period Programs the Pending ID Timer for the currently unlocked Port
*1004 Program Fan Time Programs the length of time the Fan will remain on after xmtr drop
*1005 Program Port Activity Timer Programs the Link Inactivity Timer for the currently unlocked Port
*1006 Program DTMF Mute Timer Programs the DTMF Mute Timer for the currently unlocked Port
*1007 Program CTCSS Encode Timer Programs the CTCSS Encode Timer for the currently unlocked Port
*1008 Program Alarm 1 Time Out Timer Programs how long Alarm 1 remains active after triggering
*1009 Program Alarm 2 Time Out Timer Programs how long Alarm 2 remains active after triggering
*1010 Program Alarm 3 Time Out Timer Programs how long Alarm 3 remains active after triggering
*1011 Program Alarm 4 Time Out Timer Programs how long Alarm 4 remains active after triggering
*1012 Program Alarm 5 Time Out Timer Programs how long Alarm 5 remains active after triggering
*1013 Program Aux Audio 1 Time Out Timer Programs how long Aux Audio 1 remains ON
*1014 Program Aux Audio 2 Time Out Timer Programs how long Aux Audio 2 remains ON
*1015 Program Aux Audio 3 Time Out Timer Programs how long Aux Audio 3 remains ON
*1017 Program Alarm Debounce Period Programs how long the Debounce time should be
*1018 Program the Kerchunk Filter Delay Period Programs the Kerchunk filtering time on the currently unlocked Port
*1019 Set Pending ID Speak Timer Controls how Pending ID Voice/CW IDs are processed
*1020 Set Announce Timer Sets how long the Announce Message will play after repeater activity stops
*2050xx Program Command Macro Recall Code Programs the code used to recall remapped Command Macros
*2060 Program Remote Base Prefix Programs the Prefix prepended to default Remote Base commands
*2064 Program A/D Channel Programs the channel and meter face
*2065 Program Vref Programs the voltage reference used for A/D measurements
*2066 Program Meter Alarm Programs the high and low trippoints for the Meter Alarms
*2083 Set Radio Type Select which type of radio is used as a Remote Base
*2084 Set Yaesu Type If Yaesu is selected, select which type format to use
*2085 Store Remote Base Memory Store Remote Base frequency, CTCSS and offset in non-volatile memory
*2100 Set Aux Audio Port Routing Set the port(s) to which the Aux audio should be sent
*2101 Program Aux Audio for Alarms Selects (if any) Aux Audio inputs for use in Alarms
*2102 Program Alarm Macro Program which Macro an Alarm should use
*2103 Program Message Macros Program the messages using in Message Macros
*2104 Program Command Prefix Programs the prefix to use before any default command
*2105 Program DTMF Memory Programs the DMTF sequence to be sent
*2106 Program Send DTMF Duration Programs the duration of transmitted DTMF digits
*2107 Program DTMF Pause Time Programs the period between transmitted DTMF digits
*2110x Program Tail Message Programs a Tail Message for the currently unlocked Port
*2111x Select Tail Message Selects Tail Message 1, 2 or 3 for the currently unlocked Port (0 turns off)
*2112x Select Tail Counter Sets the Tail Message Counter (0 to 254) 0 turns the counter OFF
*21999 Reset Controller Reset the controller
*31CTx Program Courtesy Tone Segment 1 Program Courtesy Tone x Segment 1
*32CTx Program Courtesy Tone Segment 2 Program Courtesy Tone x Segment 2
*33CTx Program Courtesy Tone Segment 3 Program Courtesy Tone x Segment 3
*34CTx Program Courtesy Tone Segment 4 Program Courtesy Tone x Segment 4
*4001 Program Scheduler Program the Scheduler to run automated events
*4002 Program A Macro Program a series of functions into one macro command or remap
*4003 Erase A Specific Command Macro Erase a previously stored Command Macro by Macro Number
*400499 Erase All Command Macros Erase ALL Command Macros
*4005 Program Command Macro Port Restrictions Select which Ports a Command Macro can be called from
*400699 Erase All Command Macro Port Restrictions Allows all Command Macros to be called from all Ports
*400799 Clear All Setpoints Erases all programmed Scheduler Setpoints
*5100 Set Time Sets the Real Time Clock
*5101 Set Date Sets the Calendar
*5102x Say/Don't say year as part of date Enables/disables readback of the year when the date is spoken
*5105x Bump Clock Seconds Adds or subtracts x seconds from clock time (to allow "fine tuning")
*7001x Record DVR Message Record a DVR Track x = Track 1 to 20
*7002x Erase DVR Message Erase a DVR Track x = Track 1 to 20
*700399 Erase ALL DVR Messages Erases all DVR Tracks 1 to 20
*7004x Remove last segment of DVR Message Remove the last 200 ms. of Track 1 to 20
*7005x Replace last segment of DVR Message Replace the last 200 ms. of Track 1 to 20
*70060 Recall Seconds Left Tells you the remaining recording time available
*8000 Program CW Speed Programs CW Speed of the currently unlocked Port
*8001 Program CW Tone Programs the CW Tone(s) frequency of the currently unlocked Port
*8002 Program CW ID 1 Programs the CW Message used for CW ID 1
*8003 Program CW ID 2 Programs the CW Message used for CW ID 2
*8004 Program Voice ID 1 Programs the message used for Voice ID 1
*8005 Program Voice ID 2 Programs the message used for Voice ID 2
*8006 Program Voice ID 3 Programs the message used for Voice ID 3
*8007 Program ID Extras Programs the Extra message for Voice IDs
*8008x Enable Voice IDs Enables/Disables Voice IDs: 1 = Enabled, 0 = Disabled
*9000 Program Unlock Code Programs the Unlock Code for the currently unlocked Port
*9010xxxx Program Lock Code Programs the code to lock ALL ports
*9020x Program DTMF Terminator Programs the DTMF digit used to force command evaluation
