Electrical Specifications
* Harness plugged in
The main harness connectors must be unplugged (except on the primary coil and regulator/rectifier tests), the spark
plugs removed and grounded, and by pulling the recoil starter rope briskly.
NOTE: Lighting coil output is unregulated voltage.
Component Test Value + Test Connections -
Spark Plug Cap 4000-6000 ohms cap end cap end
Oil Level Sensor Less than 1 ohm (float end down) terminal terminal
Ignition Switch Less than 1 ohm (key in OFF position) terminal terminal
4000 (Normally Open Ignition)
Ignition Coil (Primary)
(Secondary)
0.24-0.36 ohm
6800-10,200 ohms
orange/black
high tension wire
orange/red
ground
Charge Coil (1) 8.8-13.2 ohms black/red green/red
Charge Coil (2) 8.8-13.2 ohms brown/white green/red
Lighting Coil 0.08-0.12 ohm yellow yellow
Ignition Timing Sensor 80.8-121 ohms green/white brown/green
Fuel Injector 10-14 ohms terminal terminal
Injection Coil 15.2-22.8 ohms blue/white blue/white
Fuel Pump Coil 1.52-2.28 ohms orange orange
Chassis Control Unit* 9-15 DC Volts red/blue (low power)
red/black (high power)
black (low power)
black (high power)
6000 (Normally Open Ignition)
Ignition Coil (Primary)
(Secondary)
0.24-0.36 ohm
5040-7560 ohms
black/white
high tension wire
white/blue
ground
Charge Coil (1) 8.8-13.2 ohms black/red green/red
Charge Coil (2) 8.8-13.2 ohms brown/white green/red
Lighting Coil 0.08-0.12 ohm yellow yellow
Ignition Timing Sensor (1) 148-222 ohms green/white brown/green
Ignition Timing Sensor (2) 148-222 ohms green/white brown/green
Fuel Injector 11.4-12.6 ohms terminal terminal
Injection Coil 15.2-22.8 ohms blue/white blue/white
Fuel Pump Coil 1.52-2.28 ohms orange orange
Servomotor 12 DC Volts red/black (counterclockwise)
black/red (clockwise)
black/red (counterclockwise)
red/black (clockwise)
Voltage Regulator/Rectifier* 9-15 DC Volts red/blue black
8000 (Normally Open Ignition)
Ignition Coil (Primary)
(Secondary)
0.24-0.36 ohm
5040-7560 ohms
black/white
high tension wire
white/blue
ground
Charge Coil (1) 8.8-13.2 ohms black/red green/red
Charge Coil (2) 8.8-13.2 ohms brown/white green/red
Lighting Coil 0.08-0.12 ohm yellow yellow
Ignition Timing Sensor (1) 148-222 ohms green/white brown/green
Ignition Timing Sensor (2) 148-222 ohms green/white brown/green
Fuel Injector 10-14 ohms terminal terminal
Injection Coil 15.2-22.8 ohms blue/white blue/white
Fuel Pump Coil 1.52-2.28 ohms orange orange
Servomotor 12 DC Volts red/black (counterclockwise)
black/red (clockwise)
black/red (counterclockwise)
red/black (clockwise)
Voltage Regulator/Rectifier* 9-15 DC Volts
9-15 AC Volts
red/blue
yellow
brown
brown
! WARNING
Most voltages generated by the ignition system are sufficient to interrupt pacemakers! All technicians, especially
those using pacemakers, must avoid contact with all electrical connections when pulling the recoil starter rope or
after the engine has been started.
