Arctic Cat M6000 - Torque Specifications

14
Torque Specifications
NOTE: Torque specifications have the following tol-
erances:
* w/Green Loctite #609
** w/Blue Loctite #243
*** w/Oil
Torque (ft-lb) Tolerance
0-15 ±20%
16-39 ±15%
40+ ±10%
DRIVE SYSTEM
Item Secured to
Torque
ft-lb
Drive Clutch*** Engine 51
Drive Clutch Cover Movable Sheave 120 in.-lb
Ring Gear* Drive Clutch 22
Spider (Team) Movable Sheave 250
Cam Arm Pin Lock Nut Cam Arm Pin 11
Cam Arm Lock Nut (Team) Cam Arm Screw 50 in.-lb
Cam Arm Set Screw Cam Arm 19 in.-lb
Driven Clutch (Team) Driven Shaft 60
Driven Clutch** (Arctic Cat) Driven Shaft 20
Movable Sheave* (Arctic Cat) Torque Bracket 27
Movable Sheave* (Team) Torque Bracket 120 in.-lb
Chain Case (Cap Screw) Chassis 96 in.-lb
Chain Case (Torx-Head Screw) Chassis 12
Chain Case Cover Chain Case 12
Brake Caliper Chassis 25
Outside Caliper Housing Inside Caliper Housing 25
Brakeline Caliper 25
Brakeline Master Cylinder 25
Brake Caliper Shield Cover 96 in.-lb
STEERING/FRONT SUSPENSION/CHASSIS
Ski Spindle 35
Ski Wearbar 8
Ski Ski Handle 54 in.-lb
Handlebar Adjuster Block Post 15
Steering Support Mounting Block 8
Steering Tie Rod Link Steering Post 35
Steering Tie Rod Link Steering Arm 20
Steering Post Cap Riser Block 15
Steering Post Chassis 55
Steering Tie Rod Steering Arm 20
Tie Rod Spindle Arm 32
Steering Support Spar 20
Steering Support Upper Console 30 in.-lb
Steering Arm Chassis 8
A-Arm (Upper) (XF HC/M) Chassis 9
A-Arm (Upper) (ZR/XF) Chassis 23
A-Arm (Lower) Chassis (Front) 65
A-Arm (Lower) Chassis (Rear) 45
A-Arm (Upper) (ZR/XF) Spindle 45
A-Arm (Upper) (XF HC/M) Spindle 23
A-Arm (Lower) Spindle 45
Shock Absorber (ZR, XF) Spindle 32
Shock Absorber (ZR, XF) Chassis 32
Shock Absorber (XF HC/M) Spindle 24
Shock Absorber (XF HC/M) Chassis 24
Sway Bar Link A-Arm/Sway Bar Link 23
Sway Bar Mounting Bracket Chassis 9
REAR SUSPENSION
Item Secured to
Torque
ft-lb
M/XF 141”
Wear Strip Rail 50 in.-lb
End Cap/Rail Cap Wheel (M) Rail 20
Mounting Block Rail 12
Rear Wheel Axle Rail 34
Rear Arm Rail 20
Idler Arm Rear Arm 20
Front Shock Rail 50
Rear Shock Front Arm/Idler Arm 24
Rail Support Rail 20
Front Shock Front Arm 24
Limiter Strap Rail Support 72 in.-lb
Rail Rail Brace 12
Rear Tri Hub Wheel Rear Tri Hub Wheel 50 in.-lb
Rear Shock Link Front Arm/Idler Arm 24
Front Arm** Rail 52
Skid Frame** Tunnel 45
ZR/XF 137”
Wear Strip Rail 50 in.-lb
End Cap Rail 80 in.-lb
Mounting Block Rail 12
Rear Arm Rail 45
Rear Arm Idler Arm 55
Spring Slide Rail 20
Front Arm Rail 52
Coupler Block Axle Rail 40
Limiter Strap Rail Support 72 in.-lb
Rear Tri Hub Wheel Rear Tri Hub Wheel 50 in.-lb
Rear Wheel Axle Rail 34
Skid Frame** Tunnel 55**
Front Shock Rail 50
Rail Support Rail 20
Limiter Strap Front Arm 72 in.-lb
