Arctic Cat M6000 - Drive Clutch;Driven Clutch-Related Specifications; Drive System Specifications; Drive System Components; Chain Case Performance Calibrations

10
Drive System
Specifications
Drive Clutch/Driven
Clutch-Related
Specifications
Drive System Components
A list of Drive System components that are available
through the Arctic Cat Service Parts Department can be
found in the Quick Reference Guide. This information
will be useful when doing any fine-tuning on the drive
system.
Chain Case Performance
Calibrations
Model Altitude
Drive Clutch
Spring
Cam
Arm
Driven
Clutch
Spring
Torque
Bracket
Drive
Belt
Engagement
RPM
Peak
RPM
Top
Gear
Bottom
Gear
Chain
Pitch
ZR 4000 LXR 0-5000 Yellow/White 63g Black/Blue 42°/40° 0627-083 36-4000 81-8200 21T 49T 90
ZR 4000 RR 0-5000 Yellow/White 63g Black/White 44°/42° 0627-083 36-4000 81-8200 21T 49T 90
ZR 6000/XF 6000 0-5000 85/255 lb 66g 140/200 lb 48S ER3 0627-083 42-4600 81-8200 22T 48T 90
ZR 8000/XF 8000 0-5000 85/235 lb 72g 140/200 lb 66-49-.20 ER3 0627-084 36-4000 81-8200 21T 41T 86
XF 6000 High Country 0-3000 85/255 lb 66g 140/200 lb 48S ER3 0627-083 42-4600 81-8200 19T 50T 90
XF 8000 High Country 0-3000 85/235 lb 72g 140/200 lb 66-48-.20 ER3 0627-084 36-4000 81-8200 19T 50T 90
/M 6000 6-8000 85/255 lb 60g 180/240 lb 48S ER3 0627-083 42-4600 81-8200 19T 50T 90
M 8000 6-8000 85/255 lb 68g 180/240 lb 48S ER3 0627-084 42-4600 81-8200 19T 50T 90
ALIGNMENT BAR
MODEL OFFSET P/N
CENTER-TO-
CENTER
OFFSET FLOAT
6000/8000 0744-093 12.10” 1.500” None
4000 LXR 0644-246 12.10” 1.485” None
Drive
Sprocket
Gear
Ratio
Ratio Chain Engine RPM
Top Btm
6200 6400 6600 6800 7000 7200 7400 7600 7800 8000 8200 8400 8600
8800 9000
Vehicle Speed (mph)
7 Tooth
(3.0" pitch)
19 50 0.380 90 52 54 56 58 59 61 63 64 66 68 69 71 73 74 76
21 49 0.429 90 59 61 63 65 67 69 71 73 74 76 78 80 82 84 86
20 46 0.435 88 60 62 64 66 68 70 72 74 75 77 79 81 83 85 87
23 51 0.451 92 62 64 66 68 70 72 74 76 78 80 82 84 86 88 90
22 48 0.458 90 63 65 67 69 71 73 76 78 80 82 84 86 88 90 92
24 50 0.480 92 66 68 71 73 75 77 79 81 83 85 88 90 92 94 96
21 41 0.512 86 71 73 75 78 80 82 84 87 89 91 93 96 98 100 103
21 38 0.553 84 76 79 81 84 86 89 91 93 96 98 101 103 106 108 111
20 35 0.571 82 79 81 84 87 89 92 94 97 99 102 104 107 109 112 114
23 40 0.575 86 79 82 84 87 90 92 95 97 100 102 105 108 110 113 115
22 37 0.595 84 82 85 87 90 93 95 98 101 103 106 109 111 114 116 119
24 39 0.615 86 85 88 90 93 96 99 101 104 107 110 112 115 118 121 123
23 36 0.639 84 88 91 94 97 100 102 105 108 111 114 117 119 122 125 128
24 35 0.686 84 95 98 101 104 107 110 113 116 119 122 125 128 131 134 137
