Arctic Spas Kodiak User Manual

Quick Reference Guide
The Quick Reference Guide provides a quick overview of your spa’s main
functions and the operations accessible with your digital control pad.
Starting Pump 1:
Press Pump 1 button to turn Pump 1 on at low
speed. Press a second time to turn Pump 1 to high
unless it has been manually deactivated.
The Pump 1 indicator lights up when Pump 1 is on
speed.
Starting Pump 2:
Press Pump 2 button to turn pump 2 on. A second
manually deactivated.
The Pump 2 indicator lights up when Pump 2 is on
at high speed.
Starting Pump 3:
Press Pump 3 button to turn Pump 3 on. Press a
unless it has been manually deactivated.
Starting Pump 4 (Epic series only):
Press Pump 4 button to turn Pump 4 on. Press a
unless it has been manually deactivated.
Starting Pump 5 (Epic series only):
Press Pump 5 button to turn Pump 5 on. Press a
unless it has been manually deactivated.
Starting the blower:
Press the Blower button once to turn on the Therapy
Air (TA) blower.
A second time turns the TA
Setting water temperature:
Use Up or Down arrow button to regulate water
temperature. The temperature setting will be
-
tion. Water temperature can be adjusted by 1º
increments from 59 to 104ºF (15 to 40ºC).
The temperature symbol indicates the desired tem-
perature, NOT the current water temperature.
Automatic water heater start:
When water temperature is 1ºF (0.5ºC) lower than
the Set Point, the heater will automatically turn on &
heat until the water temperature reaches 1ºF (0.5ºC)
above the set point.
The Heater indicator lights up when the heater is on.
Arctic Spas
®
Quick Reference Card
Temperature unit:
Press and hold the light button for 5 seconds to toggle
between ºF and ºC.
Turning the light on:
Press Light button to turn light on. Press a second
deactivated.
The Light indicator is displayed when the light is on.
Stereo (on stereo-equipped spas):
Any user function will turn the stereo on for 2 hours.
Waterfall
The waterfall will be operated by turning pump 1 on
and adjusting a small bear paw control nearest to the
location by the model and series.
Standby mode:
Press and hold Pump 3 button for 5 seconds to enter
standby mode. The “stby” message is displayed and
Pressing any button will exit standby.
Note: If the system is turned down while the heater is
on, Pump 1 will run for an additional 3 minutes.
Pad Lockout:
There are two modes you can choose from: Full or par-
tial lock. Full lock means that all keypad functions are
locked. Partial lock means that only the basic functions
will remain accessible (pumps, blower, light).
Locking your digital control pad:
Press and hold Pump 1 for 5 seconds. The display will
show “LocP”, with “P” representing partial lock. Release
the button and the keypad will be in Partial lock mode.
Keep button pressed down for 5 more seconds if you
want to be in Full lock mode. The “LocF” message will
then be displayed.
When control pad is locked, all automatic functions will
run as usual. If a button is pressed down, a “LocP” or
“LocF” message will be displayed for 1 second. To unlock
the keypad, simply press and hold Pump 1 button again
for 5 seconds.
Boost Mode:
Press and hold Pump 2 button for 5 seconds to enable
Boost mode. In this mode, Pump 1 high speed and the
ozonator will run for 45 minutes. When enabled, “boo”
message is displayed. This mode is used to speed up
chemicals just added to the spa. Pressing any button
will exit boost mode.
The Quick Reference Card provides a quick overview of your spa’s main functions and
the operations accessible with your digital control pad.
3
4
5
Fogger Waterfall
The Fogger Waterfall is controlled by pressing
and holding the “light” button for 2 seconds.
This will activate the lights, fogger and the small
pump that operates the system. Pressing the
“light” button once will turn the Fogger/Waterfall
o. The system will stay active for 2 hours unless
it has been manually turned o using the “light”
button.
It is advisable on rst start up or restart that
water is put into the opening of the Fogger/
Waterfall to ll up the area to prevent
premature damage to the Fogger units.
Turning the light on:
If your Spa is equipped with an original
lighting package you can toggle through the
the color options by pressing the light button
ON/OFF/ON.
Press Light button to turn light on. Press a
second time to turn light o. A built-in timer
automatically turns it o after 2 hours, unless
it has been manually deactivated.
The Light indicator is displayed when the light
is on.
SpaBoy Boost (if equipped)
Press and hold the Pump 2 key for 10
seconds to initiate SpaBoy boost which
runs the SpaBoy electrode for 30 minutes
regardless of the ORP setting. When acti-
vated “Sbb” will be displayed
Invert Display
Push and hold the blower key for 20 sec-
onds to invert the display.
Starting Pump 1:
Press Pump 1 button to turn Pump 1 on at low
speed. Press a second time to turn Pump 1 to high
unless it has been manually deactivated.
The Pump 1 indicator lights up when Pump 1 is on
speed.
Starting Pump 2:
Press Pump 2 button to turn pump 2 on. A second
manually deactivated.
The Pump 2 indicator lights up when Pump 2 is on
at high speed.
Starting Pump 3:
Press Pump 3 button to turn Pump 3 on. Press a
unless it has been manually deactivated.
Starting Pump 4 (Epic series only):
Press Pump 4 button to turn Pump 4 on. Press a
unless it has been manually deactivated.
Starting Pump 5 (Epic series only):
Press Pump 5 button to turn Pump 5 on. Press a
unless it has been manually deactivated.
Starting the blower:
Press the Blower button once to turn on the Therapy
Air (TA) blower.
A second time turns the TA
Setting water temperature:
Use Up or Down arrow button to regulate water
temperature. The temperature setting will be
-
tion. Water temperature can be adjusted by 1º
increments from 59 to 104ºF (15 to 40ºC).
The temperature symbol indicates the desired tem-
perature, NOT the current water temperature.
Automatic water heater start:
When water temperature is 1ºF (0.5ºC) lower than
the Set Point, the heater will automatically turn on &
heat until the water temperature reaches 1ºF (0.5ºC)
above the set point.
The Heater indicator lights up when the heater is on.
Arctic Spas
®
Quick Reference Card
Temperature unit:
Press and hold the light button for 5 seconds to toggle
between ºF and ºC.
Turning the light on:
Press Light button to turn light on. Press a second
deactivated.
The Light indicator is displayed when the light is on.
Stereo (on stereo-equipped spas):
Any user function will turn the stereo on for 2 hours.
Waterfall
The waterfall will be operated by turning pump 1 on
and adjusting a small bear paw control nearest to the
location by the model and series.
Standby mode:
Press and hold Pump 3 button for 5 seconds to enter
standby mode. The “stby” message is displayed and
Pressing any button will exit standby.
Note: If the system is turned down while the heater is
on, Pump 1 will run for an additional 3 minutes.
Pad Lockout:
There are two modes you can choose from: Full or par-
tial lock. Full lock means that all keypad functions are
locked. Partial lock means that only the basic functions
will remain accessible (pumps, blower, light).
Locking your digital control pad:
Press and hold Pump 1 for 5 seconds. The display will
show “LocP”, with “P” representing partial lock. Release
the button and the keypad will be in Partial lock mode.
Keep button pressed down for 5 more seconds if you
want to be in Full lock mode. The “LocF” message will
then be displayed.
When control pad is locked, all automatic functions will
run as usual. If a button is pressed down, a “LocP” or
“LocF” message will be displayed for 1 second. To unlock
the keypad, simply press and hold Pump 1 button again
for 5 seconds.
Boost Mode:
Press and hold Pump 2 button for 5 seconds to enable
Boost mode. In this mode, Pump 1 high speed and the
ozonator will run for 45 minutes. When enabled, “boo”
message is displayed. This mode is used to speed up
chemicals just added to the spa. Pressing any button
will exit boost mode.
The Quick Reference Card provides a quick overview of your spa’s main functions and
the operations accessible with your digital control pad.
3
4
5
Starting Pump 1:
Press Pump 1 button to turn Pump 1 on at low
speed. Press a second time to turn Pump 1 to high
unless it has been manually deactivated.
The Pump 1 indicator lights up when Pump 1 is on
speed.
Starting Pump 2:
Press Pump 2 button to turn pump 2 on. A second
manually deactivated.
The Pump 2 indicator lights up when Pump 2 is on
at high speed.
Starting Pump 3:
Press Pump 3 button to turn Pump 3 on. Press a
unless it has been manually deactivated.
Starting Pump 4 (Epic series only):
Press Pump 4 button to turn Pump 4 on. Press a
unless it has been manually deactivated.
Starting Pump 5 (Epic series only):
Press Pump 5 button to turn Pump 5 on. Press a
unless it has been manually deactivated.
Starting the blower:
Press the Blower button once to turn on the Therapy
Air (TA) blower.
A second time turns the TA
Setting water temperature:
Use Up or Down arrow button to regulate water
temperature. The temperature setting will be
-
tion. Water temperature can be adjusted by 1º
increments from 59 to 104ºF (15 to 40ºC).
The temperature symbol indicates the desired tem-
perature, NOT the current water temperature.
Automatic water heater start:
When water temperature is 1ºF (0.5ºC) lower than
the Set Point, the heater will automatically turn on &
heat until the water temperature reaches 1ºF (0.5ºC)
above the set point.
The Heater indicator lights up when the heater is on.
Arctic Spas
®
Quick Reference Card
Temperature unit:
Press and hold the light button for 5 seconds to toggle
between ºF and ºC.
Turning the light on:
Press Light button to turn light on. Press a second
deactivated.
The Light indicator is displayed when the light is on.
Stereo (on stereo-equipped spas):
Any user function will turn the stereo on for 2 hours.
Waterfall
The waterfall will be operated by turning pump 1 on
and adjusting a small bear paw control nearest to the
location by the model and series.
Standby mode:
Press and hold Pump 3 button for 5 seconds to enter
standby mode. The “stby” message is displayed and
Pressing any button will exit standby.
Note: If the system is turned down while the heater is
on, Pump 1 will run for an additional 3 minutes.
Pad Lockout:
There are two modes you can choose from: Full or par-
tial lock. Full lock means that all keypad functions are
locked. Partial lock means that only the basic functions
will remain accessible (pumps, blower, light).
Locking your digital control pad:
Press and hold Pump 1 for 5 seconds. The display will
show “LocP”, with “P” representing partial lock. Release
the button and the keypad will be in Partial lock mode.
Keep button pressed down for 5 more seconds if you
want to be in Full lock mode. The “LocF” message will
then be displayed.
When control pad is locked, all automatic functions will
run as usual. If a button is pressed down, a “LocP” or
“LocF” message will be displayed for 1 second. To unlock
the keypad, simply press and hold Pump 1 button again
for 5 seconds.
Boost Mode:
Press and hold Pump 2 button for 5 seconds to enable
Boost mode. In this mode, Pump 1 high speed and the
ozonator will run for 45 minutes. When enabled, “boo”
message is displayed. This mode is used to speed up
chemicals just added to the spa. Pressing any button
will exit boost mode.
The Quick Reference Card provides a quick overview of your spa’s main functions and
the operations accessible with your digital control pad.
3
4
5
Firmware Revision 3.51.00.20
16

Arctic Spas Kodiak Specifications

General

Brand	Arctic Spas
Model	Kodiak
Category	Hot Tub
Language	English
