ARDETEM PECA 30 - Measurable Parameters List; NETWORK Nr2

PECA30 / 30 E : general presentation
13
ARDETEM
MEASURABLE PARAMETERS LIST
network nr
30 30E Nr MEASURED PARAMETERS 1 2 3 4 5
X X 1 UTR (mesh voltage) X X X X X
X X 2 URS (mesh voltage) X X X
X X 3 UST (mesh voltage) X X X
X X 4 Umean = (UTR+URS+UST) / 3 X X X
X X 5 VR (single voltage phase R) X
X X 6 VS (single voltage phase S) X
X X 7 VT (single voltage phase T) X
X X 8 IR (line current phase R) X X X X X
X X 9 IS (line current phase S) X X X
X X 10 IT (line current phase T) X X X
X X 11 Imean = (IR+IS+IT) / 3 X X X
X X 12 Leak current In X X
X X 13 IR max (on N minutes*) X X X X X
X X 14 IS max (on N minutes*) X X X
X X 15 IT max (on N minutes*) X X X
X X 16 COS total X X X X X
X X 17 Frequency X X X X X
X X 18 Impedance X X X X X
X X 19 Total active power X X X X X
X X 20 Total reactive power X X X X X
X X 21 Total apparent power X X X X X
X 22 Mean active power (on N minutes*) X X X X X
X 23 Mean reactive power (on N minutes*) X X X X X
X 24 Active energy OUT X X X X X
X 25 Active energy IN X X X X X
X 26 Reactive energy OUT X X X X X
X 27 Reactive energy IN X X X X X
X 28 Active energy OUT, meter 2 X X X X X
X 29 Active energy IN, meter 2 X X X X X
X 30 Reactive energy OUT, meter 2 X X X X X
X 31 Reactive energy IN, meter 2 X X X X X
X X 32 COS, phase R X
X X 33 COS, phase S X
X X 34 COS, phase T X
X X 35 Active power, phase R X
X X 36 Active power, phase S X
X X 37 Active power, phase T X
X X 38 Reactive power, phase R X
X X 39 Reactive power, phase S X
X X 40 Reactive power, phase T X
41 Analog DC input Nr 1 X X X X X
42 Analog DC input Nr 2 X X X X X
43 Analog DC input Nr 3 X X X X X
X X 44 Running time counter X X X X X
* N minutes = average value on the N last minutes ( N programmable : 1 up to 60mn)
