ARDETEM PECA 30 - Page 6

Doc. 97111-CA-G
PECA 30 / 30 E
6
The AC signal analyser can be fitted with one optionnal board :
 3 relais outputs board or 1 relay output board
Type of contacts : 2 outputs 2 contacts – 1output 1 contact
Switching capacity : 5A - 250V AC
Threshold setting : programmable (0 to 100% of measurement range)
Switching hysteresis : programmable (0 to 200% of threshlod)
Response time : programmable (0 to 25s)
 3 pulse outputs board or 1 pulse output board
Type of outputs : relay switching
Count rate : programmable (0 to 10 pulses per second)
Pulse width : programmable (50, 100 or 250 ms)
 3 analog outputs board or 1 analog output board
Galvanic insulation : 500V
Output signal : programmable : -20/20mA -10/10mA -5/5mA 0/5mA
0/10mA 0/20mA 4/20mA
Scale setting : programmable (0 to 100% of measurement range)
Permissible load : < 600Ω (20 mA)
Output resolution : 12 bits
Accuracy : <0,1% full scale for -20/20mA output (in relation to the display)
Output wave : +/-2,5mV on 50Ω load
Response time : 30 ms
 Dual output board - 3 analog / 2 relay
See 3 analog otuputs board
Type of contacts : 2 outputs 1 contact
Switching capacity : 2A - 125V Ac
Threshold setting : programmable (0 to 100% of measurement range)
Switching hysteresis : programmable (0 to 200% of threshlod)
Response time : programable (0 to 25s)
 Dual output board - 3 analog / 2 pulses
See 3 analog otuputs board
Type of outputs : relay switching
Count rate : programmable (0 to 10 pulses per second)
Pulse width : programmable (50, 100 or 250 ms
 4 logic inputs board
Input signal : 0 / 24 V (other on request)
Impedance input : 3,3kΩ / galvanic insulation : 500v
