Room air conditioner with remote condenser CMK 4000
11
11 - WiFi CONFIGURATION (FIRST START)
1. Connect the unit to the power supply.
2. Check if the WiFi status LED (dot on the bottom right of the display) is ashing. If it is not blinking, unplug the power supply and
wait for the display to turn o. Then reconnect the power supply.
WiFi status LED
3. Within 5 minutes, connect to the „UI_setup“ WiFi network by manually selecting it from the list
of available WiFi networks or by capturing the QR code shown on the side.
4. If the phone reports an internet connection error, e.g. „No internet connection“, select the option
to stay connected to the conguration WiFi „UI_setup“.
5. When the connection to the WiFi network is successfully established, the WiFi status LED will
start ashing faster.
6. Within 10 minutes, connect to the web page from the browser at http://192.168.4.1 with the
smartphone connected to the WiFi network „UI Setup“ or scan the QR displayed on the side-
Code.
7. The conguration screen shown below will appear. Select the network you want
to connect to from the drop-down menu.
8. Enter the password of the selected WiFi network.
9. Press the „WiFi Connect“ button to conrm the entered data and connect to the
WLAN.
