Argon 18 E-119 TRI+ - 15. STACK & ANGULATION ADJUSTMENT

60
E-119TRI+DISC 345A / 345B: ASSEMBLY GUIDE
15 Stack & angulation adjustement
1. Unthighten both M6 x 18mm screws (Red) from the bridge so that you can adjust the angle.
2. Moving the bridge angle creates the space to remove both spacers screws.
3. Adjust the stack as desired (max. 90mm stack). Refer to the spacers and screws lengths chart. (p.52)
