19
8.1 Fork and headset assembly
M5 x 12mm
M5 washer
1. Apply grease to the tapered surface inside
the fork where the steerer clamp will slide.
2. Insert the steerer clamp in place.
3. Place the M5 washer in the M5 x 12 mm
steerer clamp screw.
4. Apply grease to the thread of the M5 x 12
mm screw.
5. Screw the M5 x 12 mm screw for
approximately three complete turns, but
dont thighten yet.
Fork Steerer
Clamp
