E-119TRI+DISC 345A / 345B: ASSEMBLY GUIDE
21. Threaded insert change
The handlebar fixing threads on the fork and the stack fixing screw on the handlebar have removable threaded inserts.
In case of damage, the threaded inserts can be changed to repair the fork or handlebar.
1. Remove the damaged threaded insert, using a flat head screw driver.
2. Apply permanent threadlocker to the exterior threads of the threaded insert.
3. Position the threaded insert:
On the fork: Flush with the top of the locating pins.
On the handlebar: Centered in the handlebar threads.
4. Let the permanent threadlocker dry for 24 hours prior to continuing with the re-assembly.
On the fork
On the handlebar
