Argon 18 E-119 TRI+ - 10.2 FRAME ROUTING - DI2

26
E-119TRI+DISC 345A / 345B: ASSEMBLY GUIDE
10.2 Frame Routing - di2
Rear derailleur:
1. Insert the Di2 cable into the rear hole on the seat stay.
2. Guide the Di2 cable until it exits the tool box hole on the non-drive side.
3. Insert the long Di2 grommet (SKU: 80805) into the seat stay hole.
Front derailleur:
1. Run the Di2 cable through the hole on the drive side of the seat tube until it
exits the tool box hole on the non-drive side.
2. Insert the FD Di2 grommet (SKU: 81500) into the seat tube cable exit hole.
80805
81500
