KRYPTON PRO 302A 2. Frameset Inspection
BEFORE ASSEMBLING YOUR NEW KRYPTON PRO, MAKE SURE THAT YOU HAVE ALL THE FOLLOWING:
1. Frameset parts checklist (see Frameset Parts’ SKU and Description p.31-34)
2. All the necessary bolts (refer to Frameset Parts’ SKU and Description, p.31-34)
WHEN ASSEMBLING YOUR NEW KRYPTON PRO, MAKE SURE YOU FOLLOW THIS PROCEDURE:
3. Inspect the frame for cosmetic aspect (scratches, bumps, cracks, paint defect, etc.)
4. For reference, check serial number and write it on p.1
5. For optimal shifting performance, use a dropout alignment gauge to make sure that the drive-side dropout is straight
IMPORTANT:
The following parts are assembled on the frameset. When assembling the bike, you will need to adjust these parts
according to their torque specications when necessary.
Parts installed on frameset Description Screw type Torque Nm Detail
1
Front derailleur hanger
Riveted - - -
2 Chain suck guard Glued - - -
3 Seatpost Collar M5 Screw (1x) Socket head 4Nm Grease
4 Seatpost head M5 Screws (2x) Socket head 4.5Nm Grease
5 Water bottle cage screws M5 Screws (4x) Socket head 3Nm Grease
6 Removable CS cable stopper M3 Screws (2x) Flat head 1.0 -1.5Nm Grease
7 Rear derailleur hanger M4 Screw (1x) Flat head 2Nm Loctite
8 Small chain catcher M5 Screw (1x) Socket head 3Nm Nylok
9 Headset cap screw M4 Screw (1x) Flat head 0.5-1.0Nm Dry
10 Console cap screw M4 Screws (2x) Flat head 0.5-1.0Nm Dry
11 Stem’s steerer clamp screw M5 Screws (2x) Socket head 5 Nm Grease
12 Stem’s handlebar clamp screw M5 Screws (2x) Socket head 5 Nm Grease
13 HS Compressor cap screw M5 Screw (1x) Flat head 3 Nm Grease
14 HS Expander’s wedge screw Custom expander (1x) 6mm Allen socket 10 Nm Grease
