Argon 18 KRYPTON PRO 302A - 10 Seat Post Assembly

29
KRYPTON PRO 302A 10. Seat Post Assembly
The seat post is supplied fully assembled. It’s equipped with a spring-loaded
head for easy installation of the saddle.
• Unscrew both bolts slightly until the top clamp (b) and the cradle (c) are
separated enough to insert the saddle rail. Do not unscrew the bolts completely.
• Make sure that the nuts, screws threads and dome washers contact surfaces are
greased. It is recommended to grease the cradle contact surfaces as well to avoid
any creaking noise.
• Screw both bolts in order to adjust the angle of the saddle and clamp the rail.
• Tighten the bolts at 4.5 Nm.
Thetopclamp(b)andthecradle(c)canbeippedtochangethesaddleoset
between 25 or 15mm.
4.5 Nm
b
c
25mm oset. 15mm oset.
GREASE
GREASE
GREASE
