Argon 18 KRYPTON PRO 302A - Headset Installation

Steps of assembly
1. Insert the headset plastic sleeve into the top on the headtube. (apply grease)
2. Insert the required headset column, 0, 15 or 30mm, in the headset plastic sleeve. (apply grease)
*** After Step 2., complete the frame cable routing before continuing with Step 3. Refer to section 6. or 7. ***
3. Insert bottom bearing on the fork.
4. Slide the fork in the head tube of the frame.
5. Install top bearing in the headset column. (apply grease)
6. Install conical compressor ring.
7. Install stack compressor.
8. Apply grease on the headset seal to avoid any noise.
9. Install the corresponding headset cap to complete the assembly.
10.FixthecapwiththeM4atheadscrew.
11
KRYPTON PRO 302A 4.6. Headset Installation
LikeonalmostallArgon18bikesyouwillbenetofthe3Dsystem,onthe
KryptonProyoucanbenetof3positions:0mm,15mmand30mm.
0mm 15mm 30mm
