Rear derailleur cable and rear brake housing must be routed
on the right side in the inside of the downtube.
Rear brake housing need to routed above the bb carbon
sleeve.
KRYPTON PRO 302A 7. Cable and Housing Routing - Mechanical Shifting
Red line: brake cable/housing / Blue line: derailleur cable/housing
