13
KRYPTON PRO 302A 6. Cable and Housing Routing - Electronic Shifting
Rear derailleur cable and rear brake housing must be routed
above the BB carbon sleeve.
Red line: brake cable/housing / Yellow line: derailleur cable/housing
