KRYPTON PRO 302A 4. Bike Fitting
Here are the basic bike-tting steps to follow before proceeding with the complete assembly.
Consult your authorized Argon 18 Dealer to assure a proper t that takes into account your personal specications.
STEP 1: Frame Size
• Using the Sizing Chart (p.6), determine the required frame size based on your saddle height measurement. Where two frame sizes
are suggested, you can choose depending on your prefered stack, reach and stand-over clearance.
STEP 2: Saddle Height
• The seat post might need to be cut-to-size depending on your required saddle height. Refer to Min/Max Seat Post Insertion
instructions (p.7).
STEP 3: Stack Height
• Using the Sizing Chart’s Stack and Reach columns (p.6), determine the required 3D system headset size (0mm, 15mm or 30mm)
based on your recommended handlebar position.
STEP 4: Reach
 •EachKryptonProframesetincludeasizespecicstem:
• If the handlebar reach needs to be adjusted to acheive your
required position, the other stem lengths are available separately.
Refer to the Annex A. Stem Swap Kits instructions (p.35).
STEM SIZES PROVIDED ON FRAMESET SIZES
70mm XXS
80mm XS
90mm S
100mm M
110mm L and XL
120mm N/A, only available separately
