KRYPTON PRO 302A 12. Fender bracket
31
i. According to the model of fender using place the
backet at the correct hight on the seatstay.
ii. Secure the fender braket with the 2 attached
rubber band making sure that the 2 plastic parts
are well over lapping.
iii. When securing the fender on your seatstay,
make sure that the screw is not longer than 12mm.
The maximum length insertion for the
fender is the same on both seat stay.
Maximum insertion of
the screw: 10mm
