75
Compact Printer Series - User’s Manual
3. Loose the two screws (item 2) under Bottom (item 1).
4. Pull out to unlatch the front side of Middle Cover (item 3) and then
remove it upward from Bottom .
5. Loose the four screws (item 4) at both sides of Printer Module to
take Printer Module off from Bottom.
6. Find Cutter Baby Board in cutter package (item 5), and then
install onto JP16 socket on printer main board.
To Next Page
