Aries 204032 - Page 3

PAGE 3 • 204032-INS-RA • 800.798.0813 • NEED ASSISTANCE? • ARIESAUTOMOTIVE.COM
Driver Side Installation Pictured
Fig 1A
Fig 2 Fig 3
Fig 4A
Insert Bolt Plates (with
welded-on washer) into
openings in floor panel.
Center washer in opening.
Fig 1B
(2) 12mm x 30mm x 3mm
Large Flat Washers
(2) M12 Lock Washers
(2) M12 Hex Nuts
(2) M12 x 35mm Hex Bolts
(4) 12mm x 25mm x 2.5mm
Flat Washers
(2) M12 Lock Washers
(2) M12 Hex Nuts
M12 x 40mm Bolt Plate
W/Welded Washer
M12 x 40mm Bolt Plate
(no welded washer)
Front
Front
Front
Rear
Fig 4B
