Aries 204032 - Page 4

ARIESAUTOMOTIVE.COM • NEED ASSISTANCE? • 800.798.0813 • 204032-INS-RA • PAGE 4
Fig 5 Fig 6A
Complete Installation
Fig 7
Fig 8
(2) 12mm x 30mm x 3mm
Large Flat Washers
(2) M12 Lock Washers
(2) M12 Hex Nuts
12mm x 25mm x 2.5mm
Flat Washer
M12 Lock Washer 12mm
M12 Hex Nut
M10 x 35mm Hex Bolt
(2) 10mm x 20mm x 2mm Flat Washers
M10 Lock Washer, M10 Hex Nut
(2) M10 x 25mm Hex Bolts
(2) 8mm x 25mm x 2mm Flat
Washers
(2) M10 Lock Washers
Rear
Rear
Rear
Front
Fig 6B
M12 x 45mm
Short Bolt Plate
