Aristel DV-38 - D1 MDCA (Metering Pulse Card)

S
y
stem Installation Manual
D
V
-38
D1MDCA (Metering Pulse Card)
Product: DV-38 Metering Pulse CARD
Item: D1MDCA
Size: 91 mm x 21 mm
Function:
Provide signal channel of the POTS CO line 12/16KHz Metering Pulse detection.
The installation site of
D1MDCA
1
2
Figure 12. D1MDCA (Metering Pulse Card)
1. CN2: To connect to the position [CH1~4B] where upon the D1TKUC.
2. CN1: To connect to the position [CH1~4A] where upon the D1TKUC.
