Aristel DV-38 - D1 VMEA (Voice Mail Expansion Card)

S
y
stem Installation Manual
D
V
-38
D1VMEA (Voice Mail Expansion Card)
Product: DV-38 Voice Mail Expansion Card
Item: D1VMEA
Dimension: 41 mm x 41 mm
Function:
1. Signal channel of Voice Mail for port expansion where upon the designated socket.
2. Basic 2 channels on one board, Maximum capability can be expanded to 4
channels.
1
The installation site of
VMB-01
Figure 16. D1VMEA (Voice Mail Expansion Card)
1. Connect to the [DSP3A] , [DSP4A] and [DSP3B] , [DSP4B] positions where upon the
D1VMCA.
34
Arista Systems Corporation
