Aristel DV-38 - Sensor Installation

S
y
stem Installation Manual
D
V
-38
Sensor Installation
D1 MFCA
AUX
EXT
PAGE
EXT
PAGE
Figure 25. External Sensor Wiring on D1MFCA
1. D1MFCA is an option, which must be installed to provide 2 Sensor Connections.
2. This option allows the user to connect any kind of external SENSOR device, such as Door
Sensor, Smoke Detector, or Heat Sensor, among others.
46
Arista Systems Corporation
