stem Installation Manual
SYSTEM MODEL DESCRIPTION
Model Description
Remark
D1-408DK
Main Service Unit - Consisting of Plastic Cabinet + D1MBUB +
D1PWUA + D1TKUC + D1DLUB
Standard Shipment
D1CBMA
Main Service Unit - Consisting of (Plastic Cabinet + D1MBUB +
D1PWUA)
Standard Shipment
D1MBUB
Mother Board Unit
Spare Part
D1PWUA
Power Unit
Spare Part
D1TKUC
Trunk Unit - Consisting of 4 PSTN ports with Polarity Reverse, one
Fax port Connector 、 one PFT port connector and Interface for
D1MDCA and D1CIDA Connections.
Expansion Card
D1DTKA
ISDN Trunk Card - Consisting of 2 BRI S/T interface
Optional Card
D1DLUB
Digital Key Station Unit – Consisting of 8 Digital Key Station ports
Expansion Card
D1STUB
Key Station Unit – Consisting of 8 Analog Key Station ports
Expansion Card
D1SLCB
Single Line Station Card – Consisting of 2 Single Line Station Ports
Expansion Card
D1RSCC
RS232 Card – Providing 1 RS232 port and working for SMDR
Optional Card
D1VSCA
Voice Service Card – Consisting of 2 Voice Channels (60 sec. per
channel) for Auto Attendant applications
Optional Card
D1VSCB
Voice Service Expansion Card - Additional 2 Voice Channels (60
sec. per channel) for Auto Attendant applications
Optional Card
D1MFCA
Multi Function Card –
(2 Doors + 2 Relays + 2 Sensors + 1 External Paging)
Optional Card
D1MDCA
Meter Pulse Detection Card - 12KHz/16KHz Meter Pulse Detection
Optional Card
D1CIDC
FSK/DTMF CLI Interface - One Channel of POTS Caller Number
Identification Card
Expansion Card
D1RPCA
Remote Programming Card - Providing 1 standard modem port
2400 bps) and working for Remote maintenance
Optional Card
D1VMCA
Built-in Voice Mail Card - 2 ports of Voice Mail with 6.5 hours
recording time
Optional Card
D1VMEA
Voice Mail Expansion Card - one port of Voice Mail
Optional Card
D1VMFA
Expansion Flash Memory - Software control with 4 hours store
memory
Optional Card
WP5007
25-Pair Amphenol Cable – (for Station Wiring Connection)
Optional Required
9
Arista Systems Corporation
To Next Page
