S
y
stem Installation Manual
D
V
-38
D1RPCA (Remote Programming Card, 2400bps Standard Modem)
Product: DV-38 REMOTE PROGRAMING CARD
Item: D1RPCA
Size: 70.5 mm x 69 mm
Function:
1. Standard 2400bps Modem.
2. Cooperate with Aristel’s Win-SM for system remote programming and
Maintenance.
1
The installation site of
D1RPCA
Figure 14. D1RPCA (Remote Programming Card)
1. RPC: 26-Pin Connector to connect to [RPC] position where upon the D1MBUB.
32
