CS175-275-575-875 Installation Guide 125
"
The zone/user for the corresponding output must be "0" to use this location.
The last bit of the segment is not used as there are only seven outputs, the eighth bit is
reserved.
The number of users depends on the maximum number of control panel users. A
maximum of 99 users is available for the CS575 and CS875.
Segment 1-10 1
On: the code activates output 1; Off: it does not activate output 1.
2
On: the code activates output 2; Off: it does not activate output 2.
3
On: the code activates output 3; Off: it does not activate output 3.
4
On: the code activates output 4; Off: it does not activate output 4.
5
On: the code activates output 5; Off: it does not activate output 5.
6
On: the code activates output 6; Off: it does not activate output 6.
7
On: the code activates output 7; Off: it does not activate output 7.
8
On: the code activates output 8; Off: it does not activate output 8.
Location 69 Authorizing users 11 to 20 for outputs 1 to 7 (10 segments, binary data)
When activating outputs with a user code, this location can be used to restrict certain
codes from activating certain outputs. Segment 1 corresponds to user 11 and segment 10
corresponds to user 20. See
Location 68
on page 124 for more information.
Location 70 Authorizing users 21 to 30
When activating outputs with a user code, this location can be used to restrict certain
codes from activating certain outputs. Segment 1 corresponds to user 21 and segment 10
corresponds to user 30. See
Location 68
on page 124 for more information.
Location 71 Authorizing users 31 to 40
When activating outputs with a user code, this location can be used to restrict certain
codes from activating certain outputs. Segment 1 corresponds to user 31 and segment 10
corresponds to user 40. See
Location 68
on page 124 for more information.
Location 72 Authorizing users 41 to 50
When activating outputs with a user code, this location can be used to restrict certain
codes from activating certain outputs. Segment 1 corresponds to user 41 and segment 10
corresponds to user 50. See
Location 68
on page 124 for more information.
Location 73 Authorizing users 51 to 60
When activating outputs with a user code, this location can be used to restrict certain
codes from activating certain outputs. Segment 1 corresponds to user 51 and segment 10
corresponds to user 60. See
Location 68
on page 124 for more information.
Location 74 Authorizing users 61 to 70
When activating outputs with a user code, this location can be used to restrict certain
codes from activating certain outputs. Segment 1 corresponds to user 61 and segment 10
corresponds to user 70. See
Location 68
on page 124 for more information.
