CS175-275-575-8
75 Installation Guid
e
9
2 D
EF
AUL
T CODES
Default installer
code
1278 when using a fou
r-digit code
127800 when usin
g a six-digit code
Location 53
sets the number of di
gits.
Location 54 chan
ges this code.
Default master
user code
1122 when using a fou
r-digit code
112256 when usin
g a six-digit code
Location 53
sets the number of
digits
Users should
change the user code.
Download
access code
12780000
Location 30 ch
anges this code.
8
10
Table of Contents
Default Chapter
3
Table of Contents
3
1 Introducing the Csx75 System
7
2 Default Codes
9
3 Default Country Codes
10
4 Installation Guidelines
11
Installing the System
11
Wiring the System
11
Basic Installation Procedure
12
Installation Schematic
14
Installing the Control Unit
15
CS575M/CS875M (Large Metal Housing)
15
CS275/CS575/CS875 (Polycarbonate Housing)
17
CS175M/CS275M/CS575SM (Small Metal Housing)
19
Control Unit Wiring Diagram: CS-175
22
Inputs and Outputs
23
Control Unit Wiring Diagram: CS-275
24
Inputs and Outputs
25
Control Unit Wiring Diagram: CS-575 and CS-875
26
Inputs and Outputs
27
5 LCD - LED Keypad
28
Installing the Keypad
29
Mounting the Keypad
29
Wiring the Keypad
30
Wiring the Keypads Together
30
Multidrop Network
30
Star Network
30
Star and Multidrop Network
31
6 Wiring Zones
32
General
32
Dual Wiring
32
Single Wiring
32
7 Wiring Sounders
33
Wiring a Sounder with EOL Protection
33
8 Wiring Fire Detectors
36
General
36
4-Wire Fire Detector (CS275-575-875)
36
4-Wire Fire Detector (CS175)
37
Fire Escape Planning
37
9 Wiring the Outputs
38
10 Programming the System
40
Enrolling Modules and Keypads
40
Programming the LCD Keypads
40
Changing the Keypad Number and Partition
40
Adjusting the View / Brightness of the LCD
40
Setting Keypad Options
40
Setting Elapsed Increments Since Last Autotest
42
Setting the System Time and Date
42
Setting the Light Control for X-10 Devices
42
Setting the Unit and House Codes for X-10 Devices
42
Changing User Codes
42
Assigning Authority Level
43
Calling Back for Download
44
Seizing the Phone Line for Download
44
Programming Custom Messages
44
Programming the LED Keypads
45
Changing the Keypad Number and Partition
45
Setting the Starting Zone
46
Setting Keypad Options
46
Setting Elapsed Increments Since Last Autotest
46
Setting the System Date
47
Setting the System Clock
47
Changing User Codes
47
Assigning Authority Level
47
Calling Back for Download
49
Seizing the Phone Line for Download
49
Memorising Tamper-Alarms
49
Blocking Tamper Alarms
49
Blocking the Keypad Due to too Many Incorrect Codes
49
11 Programming Modules and Locations
50
Parts of the System
50
Programming Data
50
Numerical Data (ND)
50
Feature Selection Data (FSD)
50
12 Programming the Panel
52
Default Programming
52
Entering Programming Mode
52
Selecting a Module to Program
52
Loading Factory Defaults for the Controller
52
Defining the Country Code
53
Programming Via the LED Keypad
53
Entering Programming Mode
53
Exiting a Location
53
Exiting Programming Mode
53
Programming Via the LCD Keypad
54
Entering Programming Mode
54
Programming a Location
54
Discarding New Data
54
Reviewing Data
54
Invalid Data
54
Exiting a Location
54
Exiting Programming Mode
54
13 Programming with Up/Download Software
56
General
56
Wiring of the RS232 Cable
56
Programming
56
14 Control Panel Programming Locations
57
15 Using Partitioned Systems
88
Leds in Partitioning Master Mode
88
Displays in the Partitioning Master Mode
88
Armed and Ready Status
88
Arming and Disarming Multiple Partitions
88
Operating Individual Areas in the Multi-Partition Mode
89
Silencing Alarms in the Multi-Partition Mode
90
16 Setting up RF Zones - Rx8I4-16I4
91
Setting the DIP Switches
91
Module Status Conditions
92
Wiring the Rx8I4-16I4
92
Specifications
92
Programming the Rx8I4-16I4
93
Determine Transmitter Settings
93
Special Settings for Door/Window Transmitters and Wireless Smoke Detectors
93
Programming Guidelines
95
Deleting Transmitters
97
Testing Wireless Transmitters
97
17 Setting up RF Zones - Rx8W8-16W8
98
Setting the DIP Switches
99
Module Status Conditions
99
Wiring the Rx8W8-16W8
99
Terminal Description
99
Specifications
100
Programming the Rx8W8 - Rx16W8
100
Receiver Installation and Procedure (for Belgium)
100
Programming the Zone Configuration and Partition
101
Programming Guidelines
103
Deleting Transmitters
104
Testing Wireless Transmitters
104
18 CS216 Hardware Zone Expander
106
Setting the DIP Switches
106
DIP Switch 6
107
Wiring the CS216
107
Terminal Description
107
Specifications
108
Programming the CS216
108
Programming the Zone Configuration and Partition
108
19 CS534 Audio Board
109
Features Definition
109
Anti-Lockup Tone
109
Call Back Mode
110
Call-In Mode
110
Call-In Mode Answering Machine Defeat
110
High Gain and Low Gain Listen-In Mode
110
Line Hold Mode
110
Speaker Lockout
110
Wiring the CS534
110
Terminal Description
110
Specifications
111
General Operating Instructions
111
Line-Hold or Call Back
111
Line Hold Mode
111
Call Back Mode
112
Control Levels
112
Tones
113
Programming the CS534
114
Programming the CS534 Parameters
114
20 CS507 Ouput Expander Board
118
Setting the DIP Switches
119
DIP Switch 4
119
Wiring the CS507
119
Terminal Description
119
Specifications
120
Programming the CS507
121
Programming the Output Configuration and Partition
121
21 CS586 RS232 Interface
127
Wiring the CS586
127
Terminal Description
127
Specifications
128
General Operating Instructions
128
LED Indications
128
Programming the CS586
128
Programming the RS232 Parameters
128
22 Control Panel Programming Worksheets
130
23 Appendix 1: Reporting Fixed Codes in Contact ID and SIA
145
24 Appendix 2: Reporting Zone Codes in Contact ID and SIA
147
25 Appendix 3: Overview of Module Numbers
149
Keypads
149
Hardware Expander CS216
149
Output Module CS507
149
Wireless Receiver (Rx8W8 and Rx16W8)
150
Wireless Receiver (RX8I4)
150
26 Appendix 4: Service Messages
151
27 Glossary
152
28 Technical Specifications
160
Keyswitch Zones
160
29 Tasks Summary
162
30 Index
163
