CS175-275-575-875 Installation Guide 19
14. Drill 0.3 mm holes for the card guides in the box.
15. Place the card guide on the box.
16. Screw in the card guides.
17. Use card guides to mount up to 3 further pre-wired modules. See the modules for
wiring instructions.
18. Mount the RF receiver in the lid of the box. This facility is not available in every
country.
19. If you are installing an RX8I4, RX16I4 or RX48I4 CA series receiver you must insert
the antennae through the lid.
20. Wire the keypad bus for any other modules that are not in the card guides.
21. Connect the battery and power up the panel.
4.4.3 CS175M/CS275M/CS575SM (small metal housing)
This is a small metal housing that can be used with the CS175, CS275 and CS575.
