Aritech CS175 User Manual

CS175-275-575-875 Installation Guide 137
100
Expander trouble restore
0-0
101
Fail to communicate
0-0-0
102
Log full
0-0-0
103
Autotest
0-0-0
104
Exit error
0-0-0
105
Recent close
0-0-0
106
Start program
0-0-0
107
End program
0-0-0
108
End download
0-0-0
109-
121
Reserved locations
122
Partition 1, Account code
10-10-10-10-10-10
123
Partition 2, Account code
10-10-10-10-10-10
124
Partition 3, Account code
10-10-10-10-10-10
125
Partition 4, Account code
10-10-10-10-10-10
126
Format override
Seg#1
(Circle numbers to program)
Seg#2
(Circle numbers to program)
1
2
3
4
5
6
7
8
On: 1800Hz transmit; Off = 1900Hz
On: 2300Hz handshake; Off = 1400Hz.
On: Cksum parity; Off = double round parity
On: SIA area modifier
On: Allow Phone # programming.
On: Semadigit.
On: 20 p.p.s.; Off: 10 p.p.s.
On: handshake required.
1
2
3
4
5
6
7
8
On: pager formAt
On: 1400/2300 handshake
On: 8 channel fast format
On: Voice protocol
On: ContACt ID
On: SIA
On: contact ID or 4+3
On: DTMF
Segments #3 and #4 reserved
127
SIA code group 1
4
128
4/2 alarm code group 1
Seg#1
: Report Code 10’s digit 0
Seg#2: Report Code 1’s digit / 8 channel FF-Channel #
0
Seg#3: Voice Channel reported for this event
0
129
4/2 restore group 1
Seg#1: Report Code 10’s digit
0
Seg#2
: Report Code 1’s digit / 8 channel FF-Channel # 0
130
Group 1 characteristic select
Seg#1 (Circle numbers to program)
1
2
3
4
Fire (enable for fire zone).
24-hour (enable for non-fire 24-hour zone).
Keyswitch zone.
Follower (enable for burg zones that are
instant during non-entry times).
5
6
7
8
Delay 1 zone (enable to follow Timer 1 Entry/Exit
times).
Delay 2 zone (enable to follow Timer 1 Entry / Exit
times).
Interior (enable for auto bypass or stay arming).
Local Only (enable if zone is not to be reported).
Seg#2 (Circle numbers to program)
1
2
3
4
Keypad audible on alarm.
Yelping siren on alarm.
Temporal siren on alarm.
Chime
5
6
7
8
Bypassable
Group shunt
Force armable
Entry Guard
Seg#3 (Circle numbers to program)
1
2
3
4
Fast Loop Response.
Double End of Line Tamper zone.
Trouble zone (Day zone).
Cross zone.
5
6
7
8
Dialer Delay zone.
Swinger zone.
Restore reporting.
Listen-In.
Seg#4
(Circle numbers to program)
1
2
3
4
Zone Activity Monitor.
“B” Alarm.
Final set door.
Roller shutter zone.
5
6
7
8
Double Knock.
Reserved
Reserved
Reserved
