How to use the 5th Wheel (Optional)
The 5th wheel provides improved mobility and steering.
.
Activate 5th Wheel:
1. Step down on the head end of the 5th wheel activation pedal (A). (See Fig. 1)
The 5th wheel (B) will lower until it has contact with the floor.
2. Check that the brakes are unlocked and the brake pedal is in the “Free” position.
(See Fig. 2)
3. The bed is ready for movement.
Deactivate 5th Wheel:
1. Step down on the foot end of the 5th wheel activation pedal (A). (See Fig. 1)
2. Make sure the 5th wheel (B) is raised from the floor.
Fig. 1 - 5th wheel activation pedal
Fig. 2 - Free Position
B
A
Place Brake Pedal
in “Free”
p
osition
Head end
Foot end
