31
Drainage bag
rails
Rails (1) to support drainage bags, etc. are located below the thigh and
backrest sections on either side of the bed.
(Optional) The bed may also be fitted with DIN accessory rails (2).
Drainage bag rails and DIN rail
CAUTION
The maximum weight that can be safely supported by each drainage bag rail and DIN
rail is 5kg.
Head and foot
boards
The head and foot boards can be easily lifted off the bed for access to
the patient.
(Optional) The head and foot boards can each be fitted with locking
catches (1) to prevent accidental removal. To unlock a board: pull out
the catches (2) and rotate them a quarter-turn (3); the board can now
be lifted off the bed.
Locking foot board (foot end shown in this example)
After replacing a board on the bed, rotate the catches until they spring
back into the locked position.
2
1
1
2
3
